MSU 1248U-M1: Multispan Multichannel Scanner Instruction Guide

In this guide, you will learn how to set up and operate the MSU 1248U-M1 scanner, which supports 8 universal inputs and features Modbus and USB connectivity. Timestamps: [00:01] Introduction & Features – Overview of the MSU 1248U-M1 and its universal input capabilities. [00:39] Wiring & Connections – Detailed walkthrough of power, input channels, and relay wiring. [02:23] Input & Parameter Configuration – How to set scan time, skip channels, and select input types (J, K, PT100, Analog). [03:50] Relay Grouping Settings – Explaining how to assign 8 channels to 4 relay outputs using groups. [06:34] Alarm Setpoints & Hysteresis – Configuring High and Trip setpoints for process control. [07:12] Operation & Testing – Live demonstration of the scanner reacting to sensor temperature changes. [08:29] Alarm Acknowledge & Reset – How to manually reset or acknowledge triggered alarms. [08:44] Channel Scrolling Control – Steps to enable or disable automatic channel scrolling. [09:00] USB Data Logging – How to record data to a pendrive and access Excel reports. [09:30] Modbus & RTC Settings – Configuring communication parameters and the Real-Time Clock. #Multispan #ChannelScanner #TemperatureController #IndustrialAutomation #DataLogger #Modbus #MSU1248U #InstructionGuide #AutomationEngineering
