15 More Civil 3D Tips & Tricks - Alignments & Profiles

In this session we'll explore fifteen tips & tricks associated with Civil 3D alignments and profiles. Specific tips and time stamps listed below... 1. Configure Civil 3D to find non-tangent alignment geometry - 01:00 2. Set alignment style to display warnings - 02:37 3. Change tangency constraint to correct non-tangent geometry - 3:03 4. Use "Solve PI" to hold PI when editing "from object" alignments - 5:33 5. Create alignments using layout tools for predictable grip editing. - 7:25 6. Use Best Fit Alignment to find centerline between two paths - 12:12 7. Use a surface to find centerline between two paths - 14:45 8. Access "next step" commands from the Launch Pad panel - 16:38 9. Create a best fit profile from a surface profile - 18:16 10. Use Design checks to validate alignment geometry - 21:15 11. Create working styles to simplify the design process - 26:10 12. Assign Civil 3D styles using MATCHPROP - 27:53 13. Pre-load settings in Civil 3D dialog boxes - 28:37 14. Use name templates to automate/standardize object naming - 30:36 15. Use Folders to organize Civil 3D objects in the Toolspace - 33:32 For more Autodesk civil infrastructure tips, tricks and workflows, please visit https://civilimmersion.typepad.com
