PARAMETERS FT 7110 Platform Cabin/ROPS Emission Norms IIIA ENGINE Power at Rated ERPM, HP (KW) 105 HP @ 2200 ERPM Type - Natural Aspiration / Turbo Charged / Turbo Charged with Intercooler / Common Rail Direct Injection TCI Swept Volume (cc) 3680 No of Cylinders 4 Max. Torque, Nm (+/- 100-200 rpm) 420 @ 1400 ERPM PTO PTO speed- Std. 540/1000 PTO RPM @ Engine RPM 540 @ 1938 ERPM / 1000 @ 1962 ERPM TRANSMISSION Type Synchro mesh No. of Gears 24F/24R Rear Axle Reduction Type EPI Differential Lock Button (Electro hydraulic) CLUTCH Type Double Clutch (Independent PTO with Electro hydraulic Button) BRAKES Type OIB-Hydraulic asst. Hand Brake Independent Parking Brake Lever 3-POINT LINKAGES 3 point linkage (Geometry) category I / II CatII with Quick attach TPL HYDRAULICS Functions Draft & Position Control Type & Lift Capacity (Kg) E H R with 4500 Kg Auxiliary Valve 3DA/3SA (6 QRC.) convertible type with Detent STEERING Steering Power Steering FRONT AXLE Front Axle 4WD TYRE Front Tyre 14.9X24 TR 135 Rear Tyre 18.4X34 TR 135 VEHICLE Air Cleaner type DRY AIR CLEANER CAPACITIES (+/-5%) Fuel Tank capacity, ltr. 115 DIMENSIONS (+/-5%) Length, mm 4265 mm (With Front weight) Width, mm 2200 Height, mm 2820,Cabin SAFETY FEATURES BATTERY CUT-OFF SWITCH,Neutral & Clutch Safety Switch OTHER FEATURES Front Ballast (Std.)carrier + 6 nos Rear Ballast (Std.)Each side -2 nos Semi-automatic hook ( Std ). Automatic Hook Beacon Lamp Front Fender (Std.) Hyrdaulic trailer Brake
