[OBSOLETE] Computing Standard Component Values - Closest 1% Resistor Value

OBSOLETE See:    • Better Understanding of the E-Series Math ...   Update 12/13/2022 Welcome to electrical engineering with Excel. In this video we will review the E-series preferred numbers for standard component values. We will also develop a user defined function, to return the closest standard 1% component value, to the value of its input. In a later video, we will develop a function to return the closest component value for any of the e-series preferred values. Excel Electrical Engineering Visual Basic for Applications (VBA) Code for Returning Closest 1% Resistor Value VBA Code https://github.com/oldhackEE/Electric... 0:00 Intro 0:39 Standardization of Electronic Component Values 1:33 Compute Standard Component Values 2:05 E-Series of Preferred Numbers 2:54 E12 Series of Preferred Numbers 3:31 E96 Series of Preferred Number Math 4:54 Finding Closest Value - Going Backwards 5:58 Get the Base Number Using the Mantissa 7:26 Writing the Code 8:58 What's Next Correction: 8:22 Unmatched parenthesis. Code should be n = Round(Log(rx) / Log(k), 0)
