For more videos follow this link: / @dadoautomotive #AutomotiveWiring #HeadlightWiring #CombinationSwitch #HighBeam #LowBeam #PassLight #WiringColors #CarRepair #DIYCarFix #CarElectrics #MultimeterTesting #CarHeadlights Many people find automotive wiring color codes confusing, especially when it comes to the combination switch that controls the low beam, high beam, and flash (pass) lights. In this in-depth video, we break down everything you need to know about combination switch headlight wiring color codes, their functions, and how to identify each one in your vehicle. Whether you’re working on a repair, a restoration, or a custom wiring project, understanding these wiring color codes is critical for safety, efficiency, and correct operation. We’ll walk you step-by-step through each circuit, including: Low Beam Circuit: Learn which wire color controls your low beam filament, how it’s connected to the headlight bulb, and how the combination switch manages this connection. High Beam Circuit: Discover the color codes used for the high beam filament, how to trace them in your vehicle’s wiring harness, and the role of relays or direct connections. Flash/Pass Light Circuit: Understand how the flash circuit works in parallel with the high beam, and how its wire color is identified, tested, and connected. We’ll also cover wire color examples often found in cars, such as: Red with Black stripe for low beam Red with Yellow stripe for high beam Red with White stripe for flash/pass light These may vary depending on the manufacturer, but our video teaches you how to confirm your vehicle’s specific color codes using simple testing methods. If this video helps you, don’t forget to like, subscribe, and turn on notifications so you never miss our upcoming automotive wiring tutorials.
