Festo CMMP Parameter for Rotary Axis 360 Degree

How do you configure a Festo CMMP Servo Drive Drive in order to make it work as a single turn rotary axis? This is what i show you in this video. In my case the rotary axis is set to be used as 360 degree in 1/10 increments. In my application the Festo CMMP is used to operate a serve stamping press. In this tutorial i am showing not all the parameters to be set in the CMMP. Only the once that are needed for the rotary axis. 0:00 Introduction 0:56 Setting of the Modulo Positioning 1:38 Setting of the Mass Moment. ( This is important to get the Motor to correct operation.) 2:02 Setting the limit switch and the reference switch 2:35 The Analogue inputs and outputs are not used. Just a short description. 2:58 Configure the IP Address for the Profinet Communication. 3:14 Configure the factor group 3:49 The Parameter Setting for the Jog Mode. 4:11 Record Table Configuration If you like my videos i would appreciate you to consider joining my gofundme account and donationg a small amount. Thank you very much: https://www.gofundme.com/f/automation... Zeller Presscontrol Systems Gerd Zeller Tel. +49 170 961 6819 https://www.zeller-presscontrol.com info@zeller-presscontrol.com
