MAKElog#14 cheap china brushless gimbal MOD: downward facing camera view

MAKElog #14: The Brushless Gimbal together with the Brushless gimbal Controller (BGC, AlexMOS, SimpleBGC, etc.) is a good deal to get camera stabilization on a quadrocopter. Unfortunately the Gimbal does not offer downward facing (bird's eye perspective) off the shelf, so 3 easy modifications are necessary: 1. Enable mechanical full tilt movement 2. Simulate tilted cam position by installing the MEMS accelerometer sensor on a 45° wedge (e.g. made from cardboard) 3. Get gimbal balanced These steps are explained in the video. With these modifications the camera view can be changed from horizontal view to downward facing view during flight. The 6pin Atmel ISP connector at the brushless gimbal controller was added to reanimate the gimbal controller after it showed no function. ____________________________________________________ The Quadrocopter used is a QAV250 Mini Quadcopter glassy carbon fiber frame Wheelbase: 250mm CC3D Flight Controller (OpenPilot UAV autopilot platform) MT1806 2280kv Brushless Motor KV: 2280 Max Trust: 460g No. of cell: 2-3S Framework: 12N14P SimonK 12A ESC Constant Current: 12A Input Voltage: 1-3 cell Lipoly BEC: Yes (linear) [Remove middle wire to dissable] BEC Output: 5V/1A PWM: 8 KHz 5030 propeller (black) 5030 propeller (green) I hope you enjoyed! Music: Coruscate_-_Korobeiniki_Ditto.mp3 from http://ccmixter.org/files/Coruscate/4... Font used: http://www.fontsquirrel.com/fonts/And...
