GD 60- How to visualize cross sections in 3D using Strater and Voxler

Here is a summary of the main points of an online seminar on visualizing cross-sections in 3D using Strata and Voxler software. It covers exporting cross-sections created in Strata to Voxler for 3D visualization. The main points are: Strata and Voxler need to be installed with the same bitness (32-bit or 64-bit) on the same machine to communicate via COM automation. Test that Voxler scripts can run before exporting cross-sections from Strata. Cross-sections can be exported from Strata based on lithology data or other data like line logs. Multiple well selectors in Strata can create intersecting cross-sections, forming a pseudo-fence diagram. The export options in Strata allow adjusting pixel dimensions, start/end depths, and saving in IV format. P. Geo. Ricardo A Valls, M. Sc. and Geo Gadfly Valls Geoconsultant ORCID ID- https://orcid.org/0000-0002-5421-0914 Scopus Author ID: 7003369619/35335510700 ResearcherID: S-6604-2018 If you like this content, please "buy me a coffee" https://www.buymeacoffee.com/goldendr...
