New with the Old (2003 Sportster Sport)

High compression and high performance cams send a high performance message. Dual spark plugs and triple-disk brakes mean quadruple the excitement. Fully adjustable suspension and sport compound tires add to the thrill, and the textured sport seat and electronic tachometer round out this high-octane package. With its chrome exhaust, unique graphics and classic styling, the XL 1200S Sportster 1200 Sport is an eye catcher as well. 2003 Harley-Davidson XL 1200S Sportster 1200 Sport Specs: -------------------------------------------------------------------------------------------------------------------- DIMENSIONS Length 88.5 in. (2247.9 mm) Seat Height (measure laden w/ 180 lb. rider) 28.0 in. (711.2 mm) Seat Height (unladen) 29.1 in. (740.0 mm) Ground Clearance 6.7 in. (170.2 mm) Rake 29.6 degrees Trail 4.6 in. (116.8 mm) Wheelbase 60.2 in. (1529.1 mm) Tires: Dunlop Harley-Davidson Series Front – K591F 100/90-195IV Rear – K591 130/90-16 64V Fuel Capacity 3.3 gal. (12.5 L) Reserve Fuel Capacity 0.5 gal. (1.9 L) Oil Capacity 3.0 qts. (2.8 L) Dry Weight 501.0 lbs. (227.5 kg) Vehicle Weight In Running Order (unladen) 528.6 lbs. (240.0 kg) Gross Vehicle Weight Rating 948.0 lbs. (430.4 kg) -------------------------------------------------------------------------------------------------------------------- ENGINE Engine 45º OHV V2 Evolution® Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder Bore x Stroke 3.498 x 3.812 in. (88.8 x 96.8 mm) Displacement 73.2 cu. in. (1200 cc) Compression Ratio 10.0:1 Fuel System2 Carburetion ---------------------------------------------------------------------------------------------------------------- DRIVETRAIN Primary Drive Double row chain, oil bath, mechanical tensioner, 56/35 ratio Final Drive Gates carbon fiber reinforced polychain belt, 61/29 ratio Clutch Multi-plate, wet Transmission Five-speed Overall Ratio: 1st 9.047 2nd 6.210 3rd 4.823 4th 3.973 5th 3.366 ---------------------------------------------------------------------------------------------------------------- CHASSIS Frame Mild steel, twin cradle Swing Arm Mild steel, rectangular section Front Fork 39 mm telescopic w/ polished aluminum fork bracket Wheels 19 in. front, 16 in rear, 13-spoke aluminum cast Brakes: Caliper Type Dual-piston front and rear Rotor Type (diameter x width): Patented, Uniform Expansion Rotors Front (DUAL) 11.5 in. x .20 in. (292.1 mm x 5.08 mm) Rear 11.5 in. x .23 in. (292.1 mm x 5.84 mm) Suspension travel: Front wheel 6.10 in. (154.94 mm) Rear wheel 4.20 in. (106.68 mm) ------------------------------------------------------------------------------------------------------------------- PERFORMANCE Engine Torque (per SAEJ607)3: North America 72 ft. lbs. @ 4000 rpm (97.693 NM @ 4000 rpm) International 67 ft. lbs. @ 3100 rpm (90.909 NM @ 3100 rpm) Lean Angle (per SAEJ1168): Right 37.0 degrees Left 37.5 degrees ----------------------------------------------------------------------------------------------------------------- ELECTRIC Battery Sealed, maintenance-free, 12-volt, 19 amp-hour, 270 cca (per Battery Council International rating) Charging 2-amp permanent magnet alternator w/ solid-state regulator (275 watts @ 3,000rpm, 285 peak) Starting Electric start Lights: (As per country regulation) Headlamp Quartz halogen 55-watt low beam, 60-watt high beam Tail/stop lights 8w/28w (int’l: 5w/21w) Turn signal lights (self-canceling) 28w (int’l: 21w) Indicator Lamps High beam, neutral, oil, turn signals --------------------------------------------------------------------------------------------------------------------- STYLING/CONVENIENCE Engine Trim Powdercoated silver cases, black cylinders, polished covers Exhaust System Staggered shorty duals Ignition Inductive, single fire, dual plug, rpm/load advance matrix controlled by manifold absolute pressure (MAP) Front Fender Sport-style Handlebars Low-rise stainless steel Seat Textured sport seat Rear Shocks Coil over shock Instruments Electronic tachometer; electronic speedometer w/ odometer and resettable tripmeter Music by Michael Briguglio, Lone Canyon & Kristian Leo (Soundstripe.com) GEAR: Helmet - ​Sena momentum-Evo Helmet #2 - scorpion covert- x Gloves - INBIKE-Breathable-Motorcycle-Gloves- Summer Jacket - HWK Mesh Motorcycle Jacket Riding Leather Jacket - ​ScorpionExo 1909 Men's Leather Motorcycle Jacket ❱ VLOG EQUIPMENT: Helmet Camera - GoPro 9 Handle Bar Camera - GoPro 8 GoPro 7 Handle Bar Mount - Tiakia Bike Phone Mount Handle Bar Mount - FunMax 360° Stable Handlebar Holder Mount Bracket 1/4 Metal Stand External Audio Mic Mic - Movo VXR10 Universal Video Microphone ​ ❱ Bike Garage: 2021 Harley-Davidson Sporster S 2003 Harley-Davidson Sporster (S)port ❱ Links: ​https://linktr.ee/rockermotorider
