VIVO Y20 SCREEN REPLACEMENT FULL TUTORIAL

Here's a step-by-step tutorial on replacing the screen of a Vivo Y20. Vivo Y20 Screen Replacement Tutorial Tools Required: • Phillips screwdriver • Plastic opening tool or guitar pick • Suction cup • Tweezers • Adhesive strips or glue • Heat gun or hairdryer Step 1: Power Off the Device • Ensure the phone is completely powered off before starting. • Remove the SIM tray using the ejector pin. Step 2: Remove the Back Cover • Use a heat gun or hairdryer to slightly warm the back cover. • Insert a plastic opening tool between the frame and back cover. • Gently pry around the edges to loosen the adhesive. • Slowly lift the back cover to avoid damaging the fingerprint scanner cable. Step 3: Disconnect the Battery • Locate the battery connector on the motherboard. • Use a plastic spudger to disconnect the battery for safety. Step 4: Unscrew and Remove Internal Brackets • Identify the screws securing the motherboard shield. • Use a Phillips screwdriver to remove all screws. • Carefully remove the shield to expose the display and motherboard connectors. Step 5: Disconnect the Display Flex Cable • Locate the display flex cable connected to the motherboard. • Use a plastic spudger to disconnect it. Step 6: Remove the Broken Screen • Apply moderate heat to the edges of the display using a heat gun. • Use a suction cup to gently pull up the screen. • Insert a plastic pick under the screen and slide it around to break the adhesive. • Slowly lift and remove the damaged screen. Step 7: Clean the Frame • Remove any remaining adhesive using isopropyl alcohol and a cloth. • Ensure the surface is clean for the new screen. Step 8: Install the New Screen • Apply new adhesive strips or glue around the edges of the frame. • Carefully align the new screen and press it firmly into place. Step 9: Reconnect the Display Cable • Reconnect the new display flex cable to the motherboard. Step 10: Reassemble the Phone • Reattach the motherboard shield and secure it with screws. • Reconnect the battery connector. • Place the back cover onto the device. • Press around the edges to secure it properly. • Reinsert the SIM tray. Step 11: Test the New Screen • Power on the phone. • Check for touch responsiveness, display clarity, and fingerprint sensor function. Your Vivo Y20 screen replacement is now complete!
