Simple to build High Power PEMF (Pulse electromagnetic field) therapy device

Pulsed electromagnetic field therapy (PEMF therapy), also known as low field magnetic stimulation (LFMS) uses electromagnetic fields in an attempt to heal non-union fractures and depression. In addition, PEMF therapy improves sleep, mental focus, and the body’s overall performance by helping the energy output and regeneration of the body’s cells. Commercial such devices are sold at a price of several hundred to thousands of dollars, so my goal is to make the simple to build and functional device available to more people who can not afford it. This time I will also show you a simple way to make a High Power PEMF device, which gives a magnetic flux density that is about 10 times stronger than that of previous devices. The device is very simple to build and contains the following components: PWM Signal generator module ZK-PP1K (Also, you can use any of the signal generator modules used in my previous PEMF projects) 8 pcs. cheap N-channel Power mosfet transistors (in my case P50N06 , but you can use any other mosfet with similar characteristics). You can get 10 pieces at a price of 2 dollars in total. 10К Potentiometer Resistor 100 Ohm - 8 pcs. 3A diode Power supply unit from old PC (I use this PSU from Server PC, but you can use standard PSU from home PC) Special attention should be paid to the construction of the coils because the Mosfet can burn very easily. That's why I made detailed drawings with the dimensions of the coils and the wire. I am not a medical expert and I can not discuss the effect of the device, although I personally have many positive experiences from using it. I can also say with certainty that low frequency magnetic fields definitely have no negative impact, except in people where it is contraindicated. In fact, MRI imaging uses magnetic fields that are tens thousands of times stronger than those at PEMF, and as we know this type of diagnostics is completely harmless. Finally, the device is mounted in a suitable plastic box. If you are considering using this device for health-related purposes, it is crucial to consult a qualified healthcare professional to ensure safety and efficacy. This video only explains the technical aspect of this device (how to build it) . Detailed instructions and Schematic diagram at: https://www.hackster.io/mircemk/simpl... If you are interested in this area, see the Playlist with all my simple PEMF devices at:    • Simple PEMF, RIFE, Zapper  devices   If you like my job buy me a coffee: https://ko-fi.com/mircemk Visit my Youtube Channel for more Projects , DIY and How To Make videos:    / mirkopavleskimk   by mircemk SUBSCRIBE LIKE AND SHARE !!!! Thanks for your Support !
