Adding Battery Level Indication to Panasonic Dummy Battery Boxes DCC8 and DCC12

For GH3/4/5 using the BLF19 battery and the FZ200/300/330/1000/2000/2500 GX series and some G series cameras using the BLC12 battery Most of the generic dummy battery boxes are supplies with AC wall adaptors outputting 8.4v. This voltage is sufficient for the camera to operate however it does not give an on-screen indication of the voltage and moreover it limits the use of the battery box to power solutions like USB to 9v converters etc. If standard lithium ion batteries are connected at a full charge status of 8.4v then the camera will shutdown at about 7.2/7.3volts thus you are not getting the full charge potential of the cell. In this video I show you how to modify the DCC8 and the DCC12 battery boxes used in the FZ/GX and GH3/3/5 series of cameras. I show how a standard 2S lithium ion battery can then be used to provide full capacity to the camera. Additionally if you use a SB power bank and a DC-DC converter solution you can drop its output to 6.5volts. This means that the power input to boost the 5v to 6.5v is far less than if the converter had to boost it to 8.4v. The converter is more efficient, runs cooler and you will get more run time from the power bank. More information on my Photoblog at: https://www.grahamhoughton.com/tech-t...
