Plastic bag machine Lemo 850 DKTL for carrier bags with die cut handle and reinforcement patch скачать в хорошем качестве

Plastic bag machine Lemo 850 DKTL for carrier bags with die cut handle and reinforcement patch

Plastic bag converting machine Lemo 850 DKTL for the production of carrier bags with die cut handle and reinforcement patch Brand LEMO Model: IL 850 DKTL - Servo High Performance Serial Number: 470 166 Year: 1999 Main voltage: 400 volts 50 Hz Control voltage: 230 Volt 50 Power: 40 KVA Backup fuse: 80 A Certification: CE Sealing film types and film thicknesses LDPE film 2 x 30 my, up to max. 2 x 70 my HDPE film 2 x 20 my, up to max. 2 x 30 my LLDPE film 2 x 30 my, up to max. 2 x 70 my Producing the following bag heights: 300 - 800 mm (with 100 mm bottom fold 750 mm) Bag width (draw length): 220- 600 mm Line speed: Max 100 m / min. or 220 cycles per minute Glue for reinforcement sheets Type Henkel Q8733 or Type Ulitex HK 717 Consumption guaranteed under 3 g/m². Technical specifications Film unwinder max. Width 1600 mm Film roll diameter max. 1200 mm Machine welding and cutting width mm 850 Slips Film Unwinding width max. mm 140 Slips Film roll diameter max. 1200 mm Carry Bags Max. Height 800mm Bottom fold depth mm 30 - 80 Reinforcement sheet dimensions 70 x 150mm Reinforcing sheet film thickness 0.060 - 0.090 mm Pneumatically unwinding shafts Edge trimming - hardened shaft with squeeze knife Blower for side trims Welding machine for the optimization of welds in the area of folds and in the seam approach above. Extraction device with blower for punch hole waste. Welding as separation on roller Spares 1 additional welding pole reserve 1 additional welding roll reserve Fume extraction unit
