GATE 2021 SET-2 | TOC | MEALY MOORE MACHINE | GATE TEST SERIES | SOLUTIONS ADDA | EXPLAINED BY POOJA

GATE 2021 SET-2 Q58: Suppose we want to design a synchronous circuit that processes a string of 0’s and 1’s. Given a string, it produces another string by replacing the first 1 in any subsequence of consecutive 1’s by a 0. Consider the following example. Input sequence: 00100011000011100 Output sequence: 00000001000001100 A Mealy Machine is a state machine where both the next state and the output are functions of the present state and the current input. The above mentioned circuit can be designed as a two-state Mealy machine. The states in the Mealy machine can be represented using Boolean values 0 and 1. We denote the current state, the next state, the next incoming bit, and the output bit of the Mealy machine by the variables s, t, b and y respectively. What are the Boolean expressions corresponding to t and y in terms of s and b? Website: https://solutionsadda.in/ ISRO / DRDO PYQs: https://solutionsadda.in/isro/ GATE PYQs : https://solutionsadda.in/gate1/ NIC - NIELIT PYQs: https://solutionsadda.in/nielit/ ISRO Complete Analysis: https://solutionsadda.in/isro-complet... NIC-NIELIT Complete Analysis: https://solutionsadda.in/nielit/ GATE Complete Analysis: https://solutionsadda.in/gate-complet... For GATE, BARC, ISRO, CIL, AAI, HAL, UGC NET JRF, NIC NIELIT, STQC NIELIT, NVS, KVS, DSSSB PGT/TGT Test series : https://solutionsadda.in/test-series/ If you have any queries write a mail: solutionsadda.in@gmail.com Face Book Page:   / solutionsaddain-111628724482494   Telegram: https://t.me/solutionsaddaforcse
