I Designed My Own Drone ESC From Scratch (and it actually works)

I designed a 4-in-1 ESC from scratch, ordered it from JLCPCB, and put it in a real drone. In this video I explain how brushless motors work, what back-EMF is, how gate drivers and bootstrap circuits work, and how all of this comes together in a custom PCB. Then I flew it. And stress tested it at full throttle until the battery died. Links: GitHub (schematics, PCB, BOM, gerbers): https://github.com/Just4Stan/Open-4in... AM32 firmware: https://github.com/AlkaMotors/AM32-Mu... Chapters: 0:00 - Intro 0:30 - How brushless motors work 0:50 - Three phase motors explained 1:01 - Rotating magnetic fields 2:32 - Back-EMF and sensorless commutation 3:40 - Zero crossing detection 4:07 - First board test results 4:30 - ESC schematic walkthrough 4:55 - Three phase half bridge & MOSFETs 5:00 - Why you need a gate driver 5:22 - Bootstrap capacitors explained 6:09 - The microprocessor (AT32F421) 6:29 - 4-in-1 PCB design 6:51 - Current sensing 7:07 - Boards arrived — first power on 8:00 - Putting it in a drone 8:10 - Flying with friends 9:25 - Full throttle stress test 9:57 - Results #fpv #esc #electronics #pcbdesign #drone #opensource #kicad #jlcpcb #am32 #betaflight #brushlessmotor
