PAST BOARD EXAM PROBLEMS Structural Engineering & Construction Situation 18 The figure shown is a portable seat subjected to a load P = 2100 kN and is braced by a cable FG. Coefficient of friction at D and E is 0.20. Given: H1 = 0.5m x1 = 0.60m H2 = 0.25m x2 = 0.45m H3 = 0.25m x3 = 0.45m 1. Determine the reaction at C (1400 kN) 2. Determine the tensile force in cable FG (1540 kN); and 3. Determine the reaction at D (713.86 kN) Credits: 1. Intro Template:    • (FREE) 2D Square Intro (60 fps - No Text) ...   2. Music: 2.1 Driven to Success by Scott Holmes, Source: http://www.freemusicarchive.org 2.2 Instrumental (Guitar) by Carl Ernest Tayag, check his channel:    / @ninja35ful   3. Reference for the problem: Civil Engineering Reference for Licensure Examination, Volume 4, 1st Edition by DIT Gillesania (GERTC Review). Comment your suggestions or questions here. Thanks for watching! Subscribe now for more videos and click the bell icon for notifications. God bless! :) #SEC #CEBox #CivilEngineering #Engineering #ceboardexam #boardexam #prc #review #CivilEngineeringLicensureExam #structuralengineering #stem #engineeringlife #stemlife
