Make your own railing templates to use in SolidSteel parametric for Autodesk Inventor – Tutorial

Creating guardrails and railings in Autodesk Inventor is quick and easy with SolidSteel parametric using the included railing templates. But how do I create my own railing templates? We explain this in this video tutorial for both top-mounted and side-mounted railings. We admit it looks complicated at first, but just try it, it's easier than you think. Content 0:00 Introduction 0:29 Preparation 1:02 Sketch 1:51 Dimensioning the sketch 2:39 Parameters for controlling the sketch 4:47 Defining railing profiles 5:18 Define pattern 6:34 Testing the railing template 6:54 Adding railings to the database 7:57 Place railings in assembly 9:25 Railing template for side mounting Good success and if you have any questions, just write them in the comments or contact us via our website or via social media:   / apps-for-autodesk-inventor-by-klietsch-gmbh   https://klietsch.com/inventor
