How to connect a Rockwell PLC (EtherNet/IP) to PROFIBUS slave using Anybus X-gateway

In this demo, we will show how to enable communication between a Siemens IO Device using PROFIBUS and a Rockwell Control Logix PLC using EtherNet/IP. To do this, we will use the Anybus X-Gateway PROFIBUS Master from HMS. In my setup I have Rockwell ControlLogix L71 PLC and I want to communicate with a Siemens ET200S IO Device. The X-gateway acts as a translator between the two devices. So on the EtherNet/IP side the Rockwell PLC is the master – also called scanner. The slave or adapter on this side is the X-gateway. On the PROFIBUS side, the X-gateway is the master controlling the slaves – an ET200S IO device in this case. Learn more: https://www.anybus.com/products/gatew... ________________________________________________________________________ HMS Industrial Networks Socials Twitter:   / hmsnetworks   LinkedIn:   / hmsn.  . Instagram:   / hmsnetworks   Facebook:   / hmsnetworksab   #PROFIBUS #Rockwellplc #ethernetip #anybus
