OBSTA obstruction lights for building and helipad

Aircraft Warning Lights are defined as per International Civil Aviation Organization (ICAO) or Federal Aviation Administration (FAA) in USA Their role is to indicate to aircraft or helicopter pilots the presence and the shape of obstacles from any direction 3 types of lights are detailed by ICAO: High Intensity, Medium Intensity and Low Intensity There are 3 typical combinations depending on elevation and so the risk: below 45m, between 45m and 150m, above 150m Of course, in case of adjacent buildings in same area, intermediate levels lights may be omitted as per Local civil Aviation recommendations. Objective remains to orient warning lights beams around obstacles, but avoid any disturbances between each building and windows. In the first case of a building inferior to 45m, low intensity warning lights are required Our NAVILITE range, with very compact and resin moulded LED fixture offers all possibilities for mounting and wiring Each low intensity shall be spaced at longitudinal intervals not exceeding 45 m Now in the case of a higher tower above 45m but below 150m height, Medium Intensity lights are required on top. Also, if the tower is 105m above the ground or surrounding buildings, intermediate levels alternating Medium and Low intensity are needed every 52m maximum For installation on roof top and for 360° warning light beam our OFI360 Dual Colour is the perfect choice On day time the White LEDs embed into each projector will flash at 20,000 candelas. On night time, a photosensor will switch to the RED LED's circuit into the same fixture. Red at night can flash or be fixed, depending on local civil aviation recommendations In case night time only red marking is required by Civil aviation, white colour flashes are not used during day In that case we also have cost effective solution with OBSTAFLASH COMPACT (OFC) model As an engineering company, OBSTA values the work of Architects, Designers and Facade Engineers OBSTA has developed a unique projector concept to be directly mounted and integrated on vertical facades plan AROUND the obstacles. By using 2 of our patented projectors into a dedicated bracket. And implementing minimum 3 of these fixtures... ...We can highlight any complex design in all directions. At each level, we have power and control cabinets but also junction boxes option to meet any configuration OFP range offers infinite customization to spouse all curves, facades, parapets or balconies For the last and highest case of skyscrapers above 150m, ICAO recommends the use of High Intensity Warning lights Still with our modular projector technology, our OFH-120 ticks all boxes 200,000 Candelas white flashes at day 20,000 Candelas white flashes at twilight 2,000 Candelas white flashes at night (or red flashing or fixed still according to local authority) OBSTA has also developed its own speciality lights for HELIPAD's
