Leica RM2255 Automated Rotary Microtome w Controller with Holder Working скачать в хорошем качестве

Leica RM2255 Automated Rotary Microtome w Controller with Holder Working

Used, very good condition. Unit was powered on and tested as shown in the video and pictures. The control panel responds properly with no error messages. The emergency stop button functions correctly. The directional specimen holder moves up and down smoothly and operates as intended. Section thickness setting range: 0.50 - 100 μm Setting values: from 0.50 μm - 5.0 μm in 0.5 μm increments from 5.0 - 20.0 μm in 1.0 μm increments from 20.0 - 60.0 μm in 5.0 μm increments from 60.0 - 100.0 μm in 10.0 μm increments Trimming section thickness setting range: 1 - 600 μm Setting values: from 1.0 - 10.0 μm in 1.0 μm increments from 10.0 - 20.0 μm in 2.0 μm increments from 20.0 - 50.0 μm in 5.0 μm increments from 50.0 - 100.0 μm in 10.0 μm increments from 100.0 - 600.0 μm in 50.0 μm increments. Object feed: 28 mm ±1 mm, feed motion via step motor Vertical stroke: 70 mm Maximum sectioning area w/o retraction: 65 mm without specimen orientation Maximum sectioning area with retraction: 60 mm Specimen retraction: in manual sectioning mode: 5 - 100 μm in 5 μm increments; can be turned off in motorized sectioning mode: varies with the sectioning speed; can be turned off Electric coarse feed: 300 μm/s and 900 μm/s Sectioning speed: 0; 0.5 - 420 mm/s ± 10% Return speed: approx. 120 - 420 mm/s ± 10% Repositioning of holder base: north-south: ± 24 mm east-west: ± 23 mm Maximum specimen size (W x H x D): 50 x 60 x 40 mm Specimen orientation: horizontal: 8° vertical: 8° ________________________ SHOP NOW: https://www.ebay.com/itm/Leica-RM2255... ________________________ PLEASE SUBSCRIBE TO OUR CHANNEL for more videos of our latest inventory! ________________________ ABOUT US We help small businesses and research hubs access the tools they need to do their best work. We source and resell high-quality industrial and laboratory surplus products. ________________________ VISIT US AT http://www.MyCybermarkets.com
