Регулируемый регулятор 1.25V-35V 9A 300W Понижение постоянного тока до постоянного тока xl4016 скачать в хорошем качестве

Регулируемый регулятор 1.25V-35V 9A 300W Понижение постоянного тока до постоянного тока xl4016

‪@Radal05‬ Power Supply Regulator Adjustable 1.25V-35V 9A 300W xl4016 Lab bench Power Supply Regulator Adjustable 1.25V-35V 9A 300W Step down dc to dc xl4016 Ide Kreatif Video ini hanya men test modul dc to dc step down xl4016 300W. Link Pembelian : Dc Stepdown converter 0.2 - 9A 300 watt / 300w conveter https://tokopedia.link/GkPqy5MbwAb Karena bila sesuai spesifikasi. modul ini saya kira sangat murah. Bila kalian membeli perhatikan banak potensiometer pada odul, karena modul jenis ini banyak sekali dipasaran. Dan modul dc to dc converter xl4016 300W ini, mudah diganti icnya bila terjadi kerusakan. Power Supply Regulator Adjustable 1.25V-35V 9A 300W xl4016 Lab bench power supply penurun tegangan Step down XL4016 Power Supply Regulator Adjustable 1.25V-35V 9A 300W xl4016 Lab bench 0:00 Radal05 0:10 Step down XL4016 300W 0:30 cara memilih step down berkualitas 1:44 test tegangan output minimum maksimum 2:00 test regulator 2:45 test beban Step Down DC Buck Converter Regulator CC CV 9A 10A 300W 5-40V 1.2-35V DC 9A 300W Step Down Buck Converter 5-40V To 1.2-35V Power Module Modul Power Supply Regulator Adjustable 1.25V-35V 9A 300W xl4016 Lab bench Description: This is a powerful step-down (Buck) switching voltage converter. You can use this to make a constant current and constant voltage power regulator. It has large heat sinks for controlling heat build up as well as trim pots for limiting current output. The current and voltage outputs are set with independent multi-turn potentiometers. 100% brand new and high quality Use a dedicated benchmark IC, and high-precision current sensing resistor, can make more stable constant current High output current, the max output current can reach 9A. Low output ripple , high frequency capacitor reduces output ripple. Suitable for LED driver. Specifications: Input Voltage: 5V to 40V Output Voltage: 1.2V to 35V - adjustable via precision multiturn trimpot Output Current: up to 9A - adjustable via precisionm multiturn trimpot Output Power: Maximum power is about 300W (power tube temperature exceeds 65C please add cooling fan) Dimensions: 6.5 x 4.8 x 2.4 cm 8A 180KHz 40V Buck DC to DC Converter XL4016 Features Wide 8V to 40V Input Voltage Range -- Output Adjustable from 1.25V to 36V Maximum Duty Cycle 100% Minimum Drop Out 0.3V Fixed 180KHz Switching Frequency 8A Constant Output Current Capability Internal Optimize Power MOSFET High efficiency up to 96% Excellent line and load regulation Built in thermal shutdown function Built in current limit function Built in output short protection function Built in input over voltage protection Available in TO220-5L package Applications LCD Monitor and LCD TV Portable instrument power supply Telecom / Networking Equipment Power Supply Regulator Adjustable 1.25V-35V 9A 300W xl4016 Lab bench General Description The XL4016 is a 180 KHz fixed frequency PWM buck (step-down) DC/DC converter, capable of driving a 8A load with high efficiency, low ripple and excellent line and load regulation. Requiring a minimum number of external components, the regulator is simple to use and include internal frequency compensation and a fixed-frequency oscillator. The PWM control circuit is able to adjust the duty ratio linearly from 0 to 100%. An over current protection function is built inside. When short protection function happens, the operation frequency will be reduced from 180KHz to 48KHz. An internal compensation block is built in to minimize external component count. Power Supply Regulator Adjustable 1.25V-35V 9A 300W xl4016 Lab bench
