WRE 222: Week 3 Recitation - Pipe Flow, Head Loss & Cavitation Analysis

This recitation video for Water Resources Engineering 222 provides a comprehensive guide to solving complex hydraulic problems. It focuses on applying the energy equation and Darcy-Weisbach equation to analyze pipe flow, head loss, and cavitation risks in both parallel and branch systems The tutorial covers several key engineering concepts and numerical examples: Pipe Network Analysis: Learn how to use the equivalent pipe method to simplify and solve parallel pipe systems where head loss is equal across branches 02:02 Cavitation Risk Assessment: The video explains how to identify critical points—typically at high elevations or high velocities—where local pressure might drop below vapor pressure, causing physical damage to pumps and pipes 02:49 Practical Problem Solving: Detailed step-by-step solutions are provided for determining total head loss, optimal pump placement to avoid cavitation, and calculating the minimum pressure required to keep a system positive 10:56 27:59 Friction Factor Calculation: It demonstrates how to use Moody diagrams and surface roughness to accurately determine friction factors for different pipe materials like rough concrete and commercial steel 13:28
