0035: Control Logic & Breadboard | 16-Bit Computer From Scratch

CircuitVerse Project Link: https://circuitverse.org/users/160845... 16-Bit Computer From Scratch Complete Playlist:    • 0001: Very First Surface Mount Soldering |...   16-Bit Computer From Scratch Intruction Cycle Complete Playlist:    • Instruction Cycle Modules   16-Bit Computer From Scratch Register Module Playlist:    • 0008: Basic Register (Data Storage) | 16-B...   Chapters: 0:00 Intro 0:35 Clock Signals 1:24 Control Signal (Control Bits) 3:02 Fetch & Instruction Register Latches 3:59 Control Word Latch 4:28 "And Latch" Control 5:35 Bus Assert Control 6:19 Load/Inc/Dec Control 7:31 Control Timing Adjustments 10:33 Breadboarding the Control Signals 25:34 Next Steps In this video I discuss how I need to shape the control signals for the computer. I breadboard out the Control Logic needed for the NOP instruction. This gives me the control signals I need to free-run the CPU. I did not quite complete the breadboard. I forgot to hook up the relevant parts of the instruction to the EEPROM address. The video was already long enough as it is. I will clean those up when I test the signal and timing. EDIT: After posting this video, I realize that there are several issues with the breadboard. Not only are there lines missing for the address lookup, but I also wanted to latch the output and control the boards from that latched data. Obviously, there will need to be a clean-up video. I briefly considered taking this video down, but I do not like hiding from my mistakes. I will address them head-on in an upcoming video. Thank you again! Additional Tags: #Homebrew #Breadboard #PCB #KiCad #74LS #IC #SMD #schematic #CircuitVerse
