4D Systems - 3.5" Primary Display for Raspberry Pi - 4DPi-35

The 4DPi-35 is a 3.5” 480x320 Primary Display for the Raspberry Pi, which plugs directly on top of a Raspberry Pi and displays the primary output which is normally sent to the HDMI or Composite output. It features an integrated Resistive Touch panel, enabling the 4DPi-35 to function with the Raspberry Pi without the need for a mouse. Communication between the 4DPi-35 and the Raspberry Pi is interfaced with a high speed 48Mhz SPI connection, which utilises an on-board processor for direct command interpretation and SPI communication compression, and features a customised DMA enabled kernel. The 4DPi-35 is designed to work with the Raspbian Operating System running on the Raspberry Pi, as that is the official Raspberry Pi operating system. This display is capable of approximately 17 FPS running the SPI clock at 48MHz. Can be increased to 64MHz giving approximately 21 FPS. Specially designed download package is available for simple installation on a new or existing Raspbian installation. The 4DPi-35 will be in stock by the 3rd week of August 2014. http://www.4dsystems.com.au
