Tillotson Carb high and low speed needle adjustment - the way I do it.

Pretty easy! Here's how you fine tune your Tilly carb after you have CLEANED IT PROPERLY! Here is how you clean your Tillotson Carb:    • Vintage sled Tutorials #5 Rebuilding a Til...   To adjust your low speed needle - with engine warm and carb set to factory spec turn out the needle (counter clockwise) until the idle rpm rises and then drops to almost stall - then turn it in to the top rpm and then in again about 1/8 to 1/4 max - that should do it. For your high speed needle - engine warm hold the sled wide open and turn it counter clockwise until the highest rpm and then it will start to cut out - turn it back in (clockwise) to the highest rpm and then in 1/8 to 1/4 turn. that should do it! For Tilly carb parts go here and tell them louie sent you! These are real Tillotson parts so make sure you get the blow off spring and the check valve for sure! http://eccarburetors.com/store/en/
