Airzone RadianT365 Wireless Think Thermostat Configuration

When the CR2450 button battery has been inserted and the correct operation of the system LEDs has been confirmed, you can start the association process for your Wireless Think thermostat. 1. The first parameter to set is language/country. Use the control bar to select from the available options and confirm by pressing on Airzone. 2. At this point, you must open the central unit's wireless channel, either from the Blueface thermostat or from the system's main control board, by pressing briefly on the association button. The LED D19 located next to the button will show a steady light, indicating that you can start the association process for the Wireless Think thermostat. At this point, check the level of signal range, ensuring it is not less than 30%, and accept by pressing on Airzone. 3. The zone address corresponds to the number of the relay associated with the thermostat. Using the control bar, select the zone and accept by pressing briefly on Airzone. 4. The next parameter to set is the zone's associated relays. You can control several relays in the same zone from a single thermostat. Select the required option and confirm. 5. Thermostat settings, where the master control of the interface is set. The master thermostat controls all the parameters for the entire installation, setting some of them as the operating mode for the whole system. The thermostat set as zone thermostat controls the parameters for its specific zone. 6. Control stages. You can activate or deactivate the control stages such as radiant heat and cold. 7. You can also change other settings by accessing the advanced settings menu or by activating only the thermostat's basic functions. Once you have set this, if you want to return to default settings, you can reset the thermostat from the zone advanced settings menu. To do this, press and hold twice on Airzone and enter Zone. The thermostat reset can be found on the second screen. See more information about this product at https://www.airzonecontrol.com/en
