SolidWorks Sheet Metal Tutorial - METAL CLIP - 23-02-02

Try this model yourself! CLICK HERE---    • SOLIDWORKS Practice - Onshape Practice - F...   Toby's SHEET METAL TIPS & TRICKS- March 28:    • Toby's SolidWorks SHEET METAL Tips and Tri...   0:00 - INTRO 0:51 - Thanks to our sponsor - www.MySolidBox.com 2:08 - GAME PLAN - Some TRICKY areas 4:05 - First Sketch and Base Flange 5:00 - TECHNIQUE 1 - Discussion of a technique that didn't work very well... 7:54 - TECHNIQUE 2 - REVERTING BACK to original base flange 8:35 - Change original sketch to have a sharp bottom 9:00 - Create flared out section of angled flange using BASE FLANGE/TAB 9:55 - Create EDGE FLANGE on the bottom of the part using parallel to face 10:40 - Discussion of FLANGE POSITION 12:11 - Flange Length - up to vertex? CAN'T USE SKETCH POINT!! 13:35 - Double Tombstone Cut Extrude 14:20 - Discussion of NORMAL CUT option in sheet metal 17:32 - Upper Rectangular Cut - AVOID EQUALS relationship on a rectangle 19:28 - Upper Edge Flanges - Edit Flange Profile Sketch 20:38 - Cut Extrude HOLE in upper flange 21:07 - Final Flange - Flared out on sides 21:33 - COOL TRICK to calculate oddball dimensions 23:11 - Side Flange FILLETS and MIRROR 23:28 - Bottom Flange Fillets 23:40 - MIRROR ALL 24:00 - EVALUATE MASS PROPERTIES and checking my answer 24:48 - Conclusion In this #solidworks tutorial for #beginners , SolidWorks Expert TooTallToby will show #howto use the #,Bassflange tab command and #edgeflange command as well as explain how to get started creating a 3D model from a 2D print TTT SHIRTS Now Available! https://tootalltoby.com/merch/ Need a new workstation? Check out www.mysolidbox.com SOLIDWORKS Discord Server Link -   / discord   Love dogecoin? So do we!! TTT DOGE wallet address: DKfGVFe1SbeZCff3i3zPS34Wq8PafVs1Zf
