Seamless Tube and Pipe Ultrasonic Phased Array testing system GRP -USIP|xx Portal_GE IT

The latest development from GE’s Inspection Technologies business is a turnkey solution for full body inspection of tubes using Phased Array Technology on a long portal. The scanning system detects longitudinal, transverse and oblique (±45°) flaws on the internal and external surfaces of seamless tubes, measures the wall thickness and eccentricity and checks for lamination defects. The use of the Phased Array technique allows a flexible design of the scanning system. The size of the virtual probes, the track pitch on the surface, the overlap of the sound fields as well as the beam angle for the transversal flaw detection can simply be optimized by adjusting the electronic settings. Ultrasonic phased array testing machine with high throughput for large dia. seamless and ERW tubes. Inspection capabilities: Longitudinal flaws Transverse flaws Oblique flaws Laminations Eccentricity measurement Wall thickness measurement Key Facts Turnkey Testing Machine Stationary rotating tube, linear movement of test mechanics 1 or 2 carriage system layout High thruput - short test interval Phased Array probes – high sensitivity, reproducibility Paint Brush algorithm:Analysis of different flaw orientations with one single acquisition New high-end USIP|xx test electronics for superior signal quality System Performance Longitudinal and transverse flaw test, Oblique flaw test (11°/22°/33°/45°/67°), Optional: 45° gapless Lamination test (Ø 6.3 and Ø 3.2 FBH) Wall thickness and eccentricity measurement Surface test speed 2.2 m/sec Test helix 120 mm, shot distance 1-2 mm SNR typical higher than18 dB Example tube cycle time: 40-90 sec(valid for tube OD 114-406 mm, length 14 m, 2 carriage mechanics) Codes/Standards DIN EN 10246-6, -7, -14 EN ISO 10893-8, -10, -12 API 5CT, 5L, 5D Tube dimensions Outer diameter 60-750 mm Wall thickness 3-50 mm Length 6-15 m (other dimensions on request) GRP-USIP|xx Portal – new generation Phased Array UT testing of large diameter tubes (seamless/ERW) Short changeover time – high productivity High throughput – short test intervals High test speed: Parallel acquisition, Paint Brush, online analysis, high SNR Short untested ends Gapless flaw detection in 45° range Extended test functions to meed high-end requirements
