UFO³ | Fitting Instructions

The video tutorial for the assembly and installation on rear and side doors of UFO³, the ultimate range of security locks for for LCVs. UFO³ is a universal fit surface mounted range of slam locks that can be installed on the rear and side sliding door. This range features an ultra-resistant 52-54 HRC hardened steel shell and an emergency release cable that allows opening from the inside of the loading area, thanks to an unlocking system which works independently from the cylinder. Dimensions ► Ø 96 x h 50 mm Material ► Hardened Steel HRC 52:54 Finish ► Rilsan® black, white and grey Type of closure: ► Double closing or automatic \\\\\\\\\\\\ 0:03 Package content 0:48 Fitting tools REAR DOOR INSTALLATION - 25 min 1:26 Rear door installation 1:29 Cleaning and positioning the adhesive drilling template 1:41 Marking of each hole 2:02 Drilling pilot holes with Ø4 mm drill bit 2:27 Drilling out larger holes 2:47 Cleaning the holes with a countersink tool 2:59 Applying anti-corrosive metal primert 3:08 Inserting rivet nuts 3:19 Positioning rubber pad 3:33 Inserting the emergency cable 3:46 Securing the locking base plate 4:26 Installing the emergency cable 5:02 Installing the gasket for the UFO³ shell 5:19 Fastening the UFO³ shell 5:56 Opening and closing UFO³ SIDE DOOR INSTALLATION - 25 min 6:17 Cleaning the bodywork 6:25 Positioning the adhesive drilling template 6:37 Marking of each hole 6:46 Drilling pilot holes with Ø4 mm drill bit 7:00 Drilling out larger holes 7:11 Cleaning the holes with a countersink tool 7:16 Applying anti-corrosive metal primer 7:26 Inserting rivet nuts 7:41 Rubber pad positioning 7:53 Installing the gasket for the UFO³ shell 8:02 Securing the locking base plate 8:57 Fastening the UFO³ shell 9:11 Opening and closing UFO³ \\\\\\\\\\\\ Installation instructions ► https://bit.ly/ufo-download Web ► https://www.ufomeroni.com/en/ufo-3/ E-mail ► ufo@serme.it Facebook ►   / ufovanlocks
