CNC Project: Electric Guitar Built By David Picciuto w/Amana Tool Industrial Router Bits скачать в хорошем качестве

CNC Project: Electric Guitar Built By David Picciuto w/Amana Tool Industrial Router Bits

http://www.toolstoday.com Watch as we build a custom Electric Guitar from 8/4 Ash using the electrical components from a Epiphone Les Paul Special guitar with Amana Tool Router Bits and CNC Router Bits. Step 1) The 1-5/8" thick guitar body and neck is cut to shape using the Amana Tool Solid Carbide 1/4" Dia Spiral Flute Plunge Up-Cut Router Bit #46102. The outer body is only cut 1/4" deep as to save time and then David finishes cutting all the way through using a band saw. Amana Tool #46102 http://tinyurl.com/owra9j8 Feed Rate (IPM): 100 Speed Rate (RPM): 18,000 Depth per Pass: 0.1" Step 2) Flush trim (with a pre-cut template) using router bit comparable to Amana Tool Solid Carbide Spiral Trim Router Bit w/ Double Ball Bearing Router Bit #46300. Amana Tool #46300 http://tinyurl.com/pgdvw84 Step 3) Round Over the top and bottom face using router bit comparable to Amana Tool Carbide Tipped 1/4" Radius Corner Round Router Bit #49504. This provides a clean, beveled edge on the guitar body. A turbo plane and belt sander then removes the material for the arm contour. Amana Tool #49504 http://tinyurl.com/p69rry2 Step 4) Cut the white 3-ply pick guard material using Amana Tool Carbide Tipped 60° V-Groove Router Bit #45705. Amana Tool #45705 http://tinyurl.com/q2ge3aq Feed Rate (IPM): 30 Speed Rate (RPM): 18,000 Depth per Pass: 0.035" Step 5) Carve the logo into the black and gold acrylic sheet head stock using Amana Tool Solid Carbide 7.5° V-Groove Router Bit #45780. Amana Tool #45780 http://tinyurl.com/n9ncrzh Feed Rate (IPM): 30 Speed Rate (RPM): 18,000 Depth per Pass: 0.035" The guitar is then assembled by attaching the neck and then installing the electrical components. Visit our channel again soon, as the guitar will be stained in an upcoming video. Electric Guitar Built By David Picciuto Using Amana Tool Advanced CNC Router Bit Collection #AMS-132, by ToolsToday! Visit David Picciuto’s website http://tinyurl.com/q9vvuyy View Advanced CNC Router Bit Collection #AMS-132 http://tinyurl.com/nrlwb2d
