Revolutionise Your 3D BIM Workflow: Lindapter Hollo-Bolt in Tekla Structures

Manually detailing bolt connections can be time-consuming, error-prone, and frustrating. Positioning errors, incorrect spacing, and time wasted on rework all add up, slowing down projects and increasing costs. There’s a smarter way. Available to download within Tekla Warehouse, the time-saving tool enables Lindapter’s innovative Hollo-Bolt system to be incorporated directly into a Tekla user’s 3D BIM model in Tekla Structures. Link to the plug-in: https://warehouse.tekla.com/#/catalog... 🔹 Fast & Accurate Detailing – Add Hollo-Bolts as a parametric component, ensuring correct positioning every time. 🔹 Reduce Errors & Rework – The tool automatically prevents configurations that don’t meet required spacing and edge distances. 🔹 Optimise Construction Efficiency – Hollo-Bolts require access from one side only, eliminating the need for welding or through-bolting. 🔹 Multiple Configurations – Supports Hexagonal, Countersunk, and Flush Fit bolt heads for a variety of applications. 🔹 Seamless Installation – Get it right the first time with accurate digital modeling that leads to smoother on-site assembly. Renowned in the industry for manufacturing and supplying innovative steelwork connections, the Hollo-Bolt system is Lindapter’s range of CE UKCA marked expansion bolts that only require installation access to one side of the steel. Suitable for both end plate and profile-to-profile connections and with three bolt heads available (Hexagonal, Countersunk and Flush Fit), the products provide a faster alternative to welding or through-bolting, enabling steelwork contractors to reduce construction time and labour costs. The Tekla plug-in tool takes these time-saving benefits even further, providing a more efficient and accurate detailing process. What’s more, rather than detailing a bolt connection in isolation, the tool creates a parametric component. A more intelligent detailing experience, this automatically prevents users from going outside of the set parameters – for example, the positioning of the Hollo-Bolt products has to allow for a pre-stated distance between both the bolts and the inside edge of the steel section. The tool’s intelligent parametric capabilities help to ensure a correct first-time steelwork connection design, in turn contributing to a more seamless installation and assembly stage on site with minimal rework required. Maximise accuracy, minimise delays, and build smarter with Lindapter.
