Eicher 242 XTrac | 25 HP | 1 Cylinder Air Cooled Engine | Tractor Overview Specifications

EICHER 242 Product Specifications Power Range (HP Range) 18.39 kW (25 hp) Engine Make / Type EICHER AIR COOLED Cylinders 1 Cubic Capacity 1557 cc (1.56L) Fuel Injection Pump Inline Clutch Type Single Transmission Type Center shift Sliding mesh Number of Speeds 8 Forward + 2 Reverse Tyre Dimensions 15.24 cm x 40.64 cm (6.0 x 16) Front 31.51 cm x 71.12 cm (12.4 x 28) Rear Forward speed @ rated RPM 27.61 kmph PTO Type Live, Twenty one splined shaft PTO Speed (Standard) 1000 RPM @ 1616 ERPM PTO (Multi Speed & Reverse) No Lifting Capacity (Lower links at horizontal position) 1220 kgf Three Point Linkage & Controls Draft, position and response control Links fitted with CAT-2 (Combi Ball) Brake Type Sealed dry disc brakes Option: Oil immersed brakes Steering Type Mechanical Steering Option: Power Steering Electricals 12 V 88 Ah Battery Overall Length 3155 mm Overall Width 1630 mm Overall Height 2030 mm Wheelbase 1880 mm Total Weight 1710 kg Fuel Tank Capacity 34 L, Option : 45 L Accessories Tipping trailer kit, company fitted drawbar, top link
