Ingenious Solidworks Design: Unveiling Complete Detail of Drag Chain Pop-Up Transfer Conveyor Unit

In this video tutorial I will walk you thru the steps I take to design Drag Chain Conveyor with multiple Pop-up transfers. This is a (Part 3) from series of tutorials to design a 90 degree Pop-Up Transfer Conveyor with one line in and four lines out. Unit shown in this video is a Top Level assembly of the drag chain Pop-Up Unit Conveyor. From this tutorial you will learn start to finish on how to design a fully detailed functional "Real" Chain Drag conveyor assembly. All in just over two hours. Watching this Solidworks Assembly tutorial for mechanical engineering and design to the end you will learn most of the basic tools that I use when designing. Areas I will cover in this video are: Selecting Material Most of the common Feature Patterns Chain Patterns Mirrors Mates Advanced Mates Assembling Structural Metal Reference Plane Quick tip on making new parts fast Edit Parts within the assembly Drawing reference sketches in the assembly Support my Channel [Like, Subscribe, and Comment] Share your opinion in the comment section below. Cad Files Link: https://learn3dstuff.com/ Side Note: My way is not the only way to design. But this is how I do best. Hope you can get some value out of it and share in comments your experience and we can learn together. **Information in my video is for educational purpose only and not intended for commercial or harmful use.**
