OKAMOTO CNC "PRECISION" (MADE IN JAPAN) ROTARY SURFACE GRINDER

https://www.machineryvalues.com/inven... OKAMOTO CNC "PRECISION" (MADE IN JAPAN) ROTARY SURFACE GRINDER MODEL: PRG-6DXNC MFG.: 2005 CAPACITY: DIAMETER OF MAGNETIC CHUCK...... 24" MAX. SWING (COOLANT GUARD)...... 29.5" MAX. HEIGHT, UNDER 14" WHEEL ... 10.8" TABLE: DIA. OF ELECTRO-MAG CHUCK ...... 24" MAX. ANGLE (CONVEX/CONCAVE ..... +/- 5° ROTARY SPEED ................... 20 TO 150 RPM RATIO OF ROTARY & LONGITUDINAL FEED FROM OUTSIDE TO CENTER ... 3: 1 CROSSFEED (Z AXIS): LONGITUNAL TRAVEL (MAX) ........ 18" GRINDING FEEDRATE .............. 0 TO 79"/MINUTE MAX. RAPID FEEDRATE ............ 160"/MINUTE JOG FEED ....................... 0 TO 50"/MINUTE MANUAL PULSE FEED .............. 0.00001"/0.00010"/0.00100" MANUAL OVERIDE ................. 0 TO 150% VERTICAL FEED: MAXI8MUM TRAVEL ................ 12" GRINDING FEEDRATE .............. 0 TO 79"/MINUTE MAX. RAPID FEEDRATE ............ 160"/MINUTE JOG FEED ....................... 0 TO 50"/MINUTE MANUAL PULSE FEED .............. 0.00001"/0.00010"/0.00100" MANUAL OVERIDE ................. 0 TO 150% GRINDING WHEEL: STANDARD WHEEL SIZE............. 12"D x 2"W x 5"B SPINDLE SPEED .................. 1,800 RPM MOTORS: GRINDING WHEEL MOTOR ........... 10 H.P. CROSSFEED ...................... AC SERVO 1.0 H.P. VERTICAL FEED .................. AC SERVO 1.0 H.P. TABLE ROTARY DRIVE ............. 3 H.P. LUBRICATION PUMP ............... 0.1 H.P. APPROXIMATE MACHINE WEIGHT ..... 8,820 LBS. MACHINE TOOL DIMS. ............. 65"L-R x 120"F-B x 102"H EQUIPPED WITH: FANUC 21iTB CNC CONTROL 2-AXIS SIMULTANEOUS CONTROL, INCLUDING A FULLY AUTO DRESS CYCLE SHIFT-PLUNGE GRINDING FOR FAST STOCK REMOVAL, THEN TRAVERSE GRIND FOR FINE FINISH. EASY SET-UP, AUTO DRESS, MULTI-STEP GRINDING MACHINE FEATURES: "UNIQUE NON-UNIFORM TABLE FEEDS" THESE ROTARY & LONGITUDINAL TABLE SPEEDS ARE DESIGNED TO INCREASE WHEN THE GRINDING WHEEL MOVES FROM THE OUTSIDE TO THE CENTER OF THE TABLE WITH A RATIO OF 3:1 SO THAT INCREASED PRODUCTIVITY CAN BE OBTAINED AS COMPARED TO THE CONVENTIONAL CONSTANT SPEED TYPE GRINDERS. HEAVY MEEHANITE CAST IRON CONSTRUCTION NO TABLE OVERHANG TABLE TILTS, +/- 5° DEGRESS ** INSPECT UNDER POWER IN MIDWEST LOCATION ** ** SUPERB CONDITION & APPEARANCE - ORIGINAL PAINT **
