YIS Marine 10P Membrane Touch Control Panel SP5110A / SP5110D Installation Guide

Installation Guide to our revoluationary ultra thin membrane switch panel with remote control relay box. 1. Cut the included panel template 2. Use the template to locate panel and cable holes 3. Drill holes and connect the USB cable to the panel from the back 4. Remove the red sheet and apply the panel onto the desired surface 5. Mount the control box with included self tapping screws 6-1. Connect the other end of the USB cable to the Control box 6-2. Stuff the cable into the Box's trench for strain relief protection 7. Insert the Positive cable through the insulation, crimp the Ring Terminal and connect to the control box. 8. Insert the negative cable and cables to the devices to be controlled 9. Apply label stickers to the desired buttons 10. Turn on the power and test if the panel works normally There is also an App Version that works with your cellphone apps. Product Page: https://www.yismarine.com/en/product/... https://www.yismarine.com/en/product/... Official Website: https://www.yismarine.com
