Problem on Vertical pipe flow rate, difference of mercury level fluid mechanics

In a vertical pipe conveying oil of specific gravity 0.8, two pressure gauges have been installed at A and B where the diameters are 16 cm and 8 cm respectively. A is 2 metres above B . The pressure gauge reading have shown that the pressure at B is greater than at A by 0.981 N/cm2 . Neglecting all losses, calculate the flow rate. If the gauges at A and B are replaced by tubes filled with the same liquid and connected to U-tube containing mercury, calculate the difference of level of mercury in the two limbs of U-tube Please support my channel, subscribe and share my videos with friends. My aim is to provide guidance related to concepts of engineering topics
