Description Driven Workflows - Subdivisions - October 2021

Continuing the theme of last month’s Parcel Fabric workshop, we explored how the tools we and workflows used when mapping individual parcels can be used to construct a Subdivision or Certified Survey Map. Use the links below to skip to specific topics. 00:00 - Intro 01:30 - Types of Legal Descriptions 04:00 - Building the Subdivision Polygons 05:45 - The Traverse Tool 07:00 - Ground to Grid 09:15 - Only Show Active Options 12:10 - Creating the Seed 14:30 - Align Parcels 20:45 - Clip the Subdivision 22:30 - Copy Lines to Conveyance Division 23:35 - Dividing the Conveyance Division Lines 27:00 - Building the Road Centerline 31:00 -Extend Trim the Road Centerline 32:00 - Copy Parallel to Build Road Rights of Way 33:00 - Divide Exterior to Build Lot Configuration 34:20 - Construct Lot Lines 37:30 - Planarize Lines 38:30 - Create Seeds for Conveyance Divisions 40:15 - Build Conveyance Divisions 40:30 - Attribute Conveyance Divisions 41:25 - Sequential Numbering Conveyance Divisions 43:00 - Copy Lines to Tax Parcels 42:50 - Building Tax Parcels 43:10 - Sequential Numbering Tax Parcels 45:10 - Merge Points 48:00 - Topology Move on Undisplayed Layers 52:45 - Align Features Discussion
