SolidWorks CAM : Face Milling & Drilling Hole

SolidWorks CAM 2.5 Axis Feature Types When you execute the New 2.5 Axis Feature command to define a 2.5 Axis feature, the 2.5 Axis Feature Definition: Select Entities dialog box will be displayed. This dialog box allows you to define the 2.5 Axis feature by type. The type of feature controls the operations that are created for the feature and influences the resulting toolpath. After you select the face, sketch, edges or loops required to define the feature, SOLIDWORKS CAM validates that the selected geometry forms a valid shape for the selected feature type. -Face Feature A planar face parallel to the Mill Part Setup. A Face Feature can be machined to the material extents or the extents of the feature itself. -Hole Any round shape. Strategies can be assigned as Drill, Bore, Ream, or Tap.
