Repair DJ Gear | Traktor S4 Disassemble Procedure

Please subscribe! *Update: Just noticed the typo! :) How to disassemble the Traktor S4! Note: Take pictures of connector routing before disconnecting for reference. Replacement Faders, USB Ports, Rebuild Kits, RCA Caps, and Innofader Upgrades! www.repairdjgear.com Tools Needed: Philip Screw Driver -9mm and 10mm socket -Plastic edge pry tool -Razor blade -Solvent(plastic safe) -Warm soapy water -Soldering tool -Remove knobs of POTS and faders -Remove the fascia plates Note: Use a plastic safe solvent to loosen the adhesive material from bottom. -Once the fascia plates are removed, clean them with warm soapy water. They will still be tacky enough to reinstall later. -If you need adhesive strips. We have them available for purchase. -The center fascia is plastic which can bend more than the deck plates. -The deck plates are aluminum. Avoid severe bending when removing. -Remove 22 with a 9mm and 10mm socket. -Place a mat, towel, or foam pad on top of the controller and flip it over carefully to catch hardware. -Tap the bottom to shake off the hardware and LED inserts. -Remove 22 screws from bottom. One is under the NI sticker. -Remove two screws from soundcard and two pot knobs from front of controller. -Label and remove 12 connectors from the Soundcard PCB. -Remove POT knobs from the headphone PCB. -Remove the connectors. -Remove 22 black screws from the PCBs. -Disconnect job wheel and deck PCB connectors. -PCBS can now be removed and serviced. These are through our Amazon Associates program - We get a small kick back from Jeff B. Traktor S4 MK2 - https://amzn.to/3q8TAkL Traktor S4 MK3 - https://amzn.to/3BcRFlh Hard Case - https://amzn.to/3RwJvJU
