Basic Measurements How-To w/an OTDR & Optical Switch Box | Yokogawa Test&Measurement

How to Use an OTDR with an Optical Switch Box for Basic Measurements The AQ3550 Optical Switch Box from Yokogawa Test&Measurement is a 12-channel OSW that, when paired with an optical time domain reflectometer, improves workflow efficiency. In this video, we demonstrate how to switch channels on an AQ3550 from the screen of an AQ1210 OTDR for quick and easy measurement of fiber optic cable. Please note that product specifications may change without notice due to firmware updates, etc. For the most up-to-date information, please visit the firmware download page (accessible via the link below). LEARN MORE AQ1210 Series Optical Time Domain Reflectometer https://tmi.yokogawa.com/solutions/pr... AQ3550 Optical Switch Box https://tmi.yokogawa.com/solutions/pr... _______________________________________________________ Connect with Yokogawa Test&Measurement on LinkedIn:   / yokogawa-test&measurement   Contact Yokogawa Test&Measurement: https://tmi.yokogawa.com/contact/?utm... Yokogawa has been developing measurement solutions for 100 years and consistently finds new ways to give R&D teams the tools they need to gain the best insights from their measurement strategies. The company has pioneered accurate power measurement throughout its history and is the market leader in digital power analyzers. Yokogawa Test&Measurement instruments are renowned for maintaining high levels of precision and for delivering value far longer than the typical shelf life of such equipment. The Precision Makers of Yokogawa Test&Measurement believe that precise and effective measurement lies at the heart of successful innovation - and has focused its own R&D on providing the tools that researchers and engineers need to address challenges great and small. _______________________________________________________ Chapters: 00:00 Connection Configuration 01:11 Measurement Procedure 02:43 Real-time Measurement (Channel Switching: Manual, Auto Save: OFF) 03:58 Averaging Measurement (Channel Switching: Auto, Auto Save: OFF) 05:53 Averaging Measurement (Channel Switching: Auto, Auto Save: ON)
