Dextra CR BAR 1080 - Post-tensioning bar

Introducing the High-Tensile CR Bar 1080, the ultimate solution for post tensioning bar needs in bridge applications. This fully threaded bar is specifically designed for high strength and flexibility, making it a top choice for engineers and builders. With its quenched and tempered properties, the CR Bar 1080 ensures optimal performance and reliability. Key Features: High-Tensile Strength: Quenched and tempered to achieve exceptional properties. Fully Threaded: Cold-rolled thread facilitates easier installation and continuous thread connections at any point. Cuttable on Site: Provides flexibility in installation, allowing adjustments and customizations as needed. High Impact Resistance: Engineered to withstand significant force and stress. High Fatigue Performance: Ensures longevity and durability in demanding applications. Product Specifications: Diameter Range: Available from 26.5mm to 75mm, in bar grade 1080. Thread Specifications: Triangular ISO metric thread with a pitch of 6mm for ≤ OD40mm and 8mm for ≥ OD47mm. Length: Up to a maximum of 11.8m. Accessory Range: Complete set of couplers, washers, nuts, and plates available. Applications: Ideal for permanent or temporary connections between steel and concrete elements, concrete to concrete elements, or steel to steel elements. Perfect for bridge applications requiring post tensioning bars with high strength and flexibility. Experience the future of bridge construction with the High-Tensile CR Bar 1080. Its superior properties and versatile applications make it the perfect choice for your next project.
