STATIONARY COMPACTOR

GENERAL FEATURES The single blade compactor is ideal for compacting moist municipal solid waste and bulky materials. The bottom of the compression chamber constructed with a single plate creates a chute that enters the box directly. The oil-hydraulic unit is placed under the bottom plate, thus achieving a fully watertight structure. The single blade compactor features a compacting system consisting of a blade sliding on bronze shoes within “Hoesch” guide rails, hinged at the top onto the compactor’s frame to permit the tilting motion. The waste is compacted by the tilting movement of the two guide rails . The blade is moved vertically by oil-hydraulic cylinders. The compacting system assures a thrust up to 40 tonnes.The single blade roll on/off compactor is available in two versions The compactor provided with tilt opening using connection to the hydraulic system of the transport tractor or truck with roll-off equipment. The hatch free opening prevents it from rubbing against the waste on the groundand allows the equipment to tilt completely to conveniently extract the material from the box. Tightness between box and hatch is assured by a gasket on the two side jambs on the entire height and on the lower casement. Thank to this blocking system the hatch does not slide on the gasket but is supported, assuring excellent water tightness and long service life of the gasket. Rear door made of frame covered 4mm (S420) curved plate with two 15 mm center plate reinforcement for the rear door hook, diameter 60 mm. Rear door hinged on the top frame and fitted with rubber seal to prevent leakage Rear door is locked and sealed with four (4) manual locks TYPE OF WASTE SUITABLE FOR COMPACTING Municipal solid waste and similar Waste packaging (boxes, cellophane, polystyrene etc.) Materials easily compressible (plastic bottles, light plastic boxes, industrial process waste etc.
