NOT Gate working Principle of Operation A NOT gate is a logic gate that inverts the digital input signal. For this reason, a NOT gate is sometimes is referred to as an inverter (not to be confused with a power inverter). A NOT gate always has high (logical 1) output when its input is low (logical 0). Conversely, a logical NOT gate always has low (logical 0) output when the input is high (logical 1). The logical symbol for a NOT gate If the input binary variable of a NOT gate is considered as A, then the output binary variable of the gate will be Ā. As the symbol of not operation is ( – ) bar. If the value of A is 1. then Ā = 0 and in the opposite if the value of A is then Ā = 1. If the input binary variable of a NOT gate is considered as A, then the output binary variable of the gate will be Ā. As the symbol of not operation is ( – ) bar. If the value of A is 1. then Ā = 0 and in the opposite if the value of A is then Ā = 1. NOT Gate Transistor Circuit Diagram A NOT gate can easily be realized by using a simple bipolar transistor. The transistor circuit diagram of a NOT gate (also known as a transistor inverter) Thank You for watching
