Button Control LED using by Arduino with code||Push Button and LED control with the Arduino

Code and Connection: Connection is: LED positive+13 no pin of Arduino LED Ground+GND of Arduino 8 no pin of Arduino+Button any one Leg GND of arduino + Button other Leg Code: int led=13; int but=8; int sv=0; void setup() { pinMode(led,OUTPUT); pinMode(but,INPUT); Serial.begin(9600); } void loop() { sv=digitalRead(but); Serial.println(sv); delay(1); if(sv==1) { digitalWrite(led,HIGH); delay(500); } else { digitalWrite(led,LOW); } } Arduino Basic:   • Arduino  The Magical Board||About Arduino|...   LED blinking :   • LED Blinking Using By Arduino With code||E...   PWM brightness control pin:   • PWM Led Brightness Control Pin with code||...   RGB control by comment:   • How to use an RGB LED with Arduino with co...
