Vertical Transfer Press for Cartridge Case - 240 Parts/Min | Ammunition Machinery

This is a Transfer Press which is equipped with two(2) Rows and Each Row contains Eight (8) Stations. Thus this is a 8+8=Total 16 Station Press with 8 stations on each Rows. The Brass Sleeves are fed to this Multi-station Vertical Transfer Press to form Brass Cartridge Cases. The Brass Sleeves are passed through multiple stations of the Press via Transfer Bar (actuated by each stroke of the Press) which transfers the component to the next station for consecutive operations as detailed below: Station 1: Sleeve Feeding Station 2: Indenting Station 3: Heading Station 4: Fire Hole Piercing & its Presence Checking. Station 5: First Necking Station 6: Second Necking Station 7: Mouth Sizing Station 8: Cartridge Case Exit/Eject Above operations are also repeated alongside on the second row Number of Strokes/Speed: From 80 – 150/Minute (Adjustable) Production Capacity: 14,400 Pieces/Hour at 100% Theoretical Efficiency OUR CONTACT: BIPROIMEX & CO. PVT. LTD. 26A, Rifle Range Road, Kolkata-700019. India Tel: 0091-33-22809487 ; 22893673 Mobile & Whatapp: +91-8910673234 Email: biproimexmailbox@rediffmail.com
