Repaired & Rebuilt DYS BLG3SN Gimbal with STorM32-BGC and BT module

Repaired & Rebuilt DYS BLG3SN Gimbal with STorM32-BGC Gimbal Controller and BT module Recently I sold a Storm32 Gimbal Controller and I was asked to install and set it up, in a dead DYS Gimbal purchased online… This is not the first DYS Gimbal I am building, but it is the worst I have ever imagined :( Some of the gimbal parts are wrong because they cannot slide freely for balancing. All three DYS BGM4108-130 are probably counterfeit products since the electrical characteristics are totally different from the DYS specification. Most Gimbal Controllers require brushless motors with Ri = 10 Ohms or more, for good results. DYS specification for BGM4108-130 motors specify 15.5 Ohms but all 3 motors (marked DYS) have only 8.9 Ohms which caused me a lot of troubles to setup properly this gimbal. I had to replace all the external wires which were very thin (0.5A max.) and low quality. I also had to re-solder all the internal wires which were literally “in the air’. After many hours of setup fiddling, I have managed to find a compromise solution with everything working using for RC Gimbal Control a FrSky Taranis Transmitter, X8R Receiver - SBUS and 6 channels. Thanks for watching! ----------------------------------------------------------------------------------------------------- DYS BLG3SN 3axis Brushless Gimbal STorM32-BGC Gimbal Controller with BT module (it has always been a pleasure using this gimbal controller – thanks OlliW!) Additional 2nd IMU (mpu6050) mounted on top of the antivibration plate – because the onboard IMU cannot be used due to its location. MP1484EN Voltage Step Down Regulator (adjusted for 6S LiPo Battery 22.2V down to 15.5V @ 3A) 3MM INFRARED EMITTING DIODE for RC Camera Control (Video & Photo – On / Off). SONY NEX-6 Camera
