10MHz RF Oscillator || Plasma Flame Generator

High-frequency generator circuit using IRFP460 MOSFET. ⚠️Warning: Direct contact with metallic objects exposed to radiofrequency fields may cause burns. In direct current, the discharge is a silent torch, like the flame of a candle. The first inductor has no critical value and can be built with thick or thin wire. The primary coil needs to have between 3 and 5 turns (in my case, thick wire). The secondary coil can have between 25 and 70 turns; experimenting with various sizes is an interesting option. The only component you need to pay attention to is the 120pF capacitor (in my case); values ​​much higher or lower will not work. Some circuits use a variable capacitor to obtain the ideal capacitance for the circuit to oscillate. Power supply: 35V Frequency: between 8 and 11 MHz
