MFOS LFO sync modification

Here I demo a modification to the Music From Outer Space Voltage Controlled Low Frequency Oscillator (known to its friends as MFOS VC LFO). It's a sync input, which allows you to use an external trigger to tell the LFO "start your waveform RIGHT NOW". Adapted from a design by Tim Parkhurst. I probably should have mentioned that while I did this in Kosmo format, you should be able to use this mod for a Eurorack version too — you just have to find space on the front panel for another switch and jack, or make a new front panel, and find some way to mount the auxiliary PCB. Electrically it's all the same. Erratum: At 07:00 where I said 2N3819 I meant 2N5458. 00:00 Intro 00:10 How would you do this? 02:43 How you would do this 07:17 The circuit board 08:00 Demo 12:48 Wrapup Schematics, Gerber files, documentation, et cetera at https://gitlab.com/rsholmes/MFOS_VC_LFO . Blog post: https://analogoutputblog.wordpress.co... Music: Ringtone by Rich Holmes
