5PA Flexo Printing Machine. Mid-line. TCY inline

FEEDING SECTION • SUN lead edge feeder with accurate feeding for all flutes and warped sheets. • Available for skip feed and feed interrupt. • Auto zero-set for feeding position with one push button. • Non back- lash transmission gear system. • All gap adjustment via eccentric device with corresponding scale. • Frequency inverter drive with variable suction control. • Optional- Dust vacuum cleaner for sheet PRINTING SECTION • Top print. • Highly accurate printing registration. • Laser engraved ceramic anilox roll. • Rubber roll system as standrd. • Auto zero- set for printing position with one push button. • Optional- Ink chamber blade device with programming auto wash ink system. • Optional- Vacuum transfer device for sheet. • Optional- Printer unit roll out with side track device. SLOTTER CREASER SECTION • Dual slotting shafts for leading knives and trailing knives. • Separate shaft for pre-creaser and creaser ensure sufficient crushing and creasing. • Auto zero- set for slotting knife with one push button. • Standard digital counter with pre- set one order, auto positioning of slotting knives for box panel dimension. • Optional- Central york head moveable. • Optional- Single slotting shaft for both leading and trailing knives. DIE CUTTER SECTION • Heavy duty die cutting drum. • Hydraulic oscillation movement for anvil drum to prolong anvil life time. • Auto zero- set for die cutting position with one push button. • Optional- Anvil trimming and anvil drum synchronized drive. • Optional- Die cutter unit roll out with side track device. FOLDER GLUER (FGT) • Upper suction belt with down folding for high performance. • Sheet inclined detector equipped in folding section will stop machine automatically. • Independent drive for bottom belt speed adjustment through touch screen control. • Side guiding wheel tracking box folded edge for accurate flap gap. • Frequency inverter drive control system. • Optional- “VALCO” Flexoseal system. COUNTER EJECTOR (FGT) • Full integrated construction with HMI control device. • Quick positioning via AC servo control. • Top loading device for receiving and stacking boxes. • Suitable for die cutting box use. • Accurate counting quantity of boxes and eject bundle of boxes. • Upper holding wheel to deliver bundle of boxes without collapse. • Full closed unit for safety operation. Website: tcy.com Facebook: facebook.com/TCY-Machinery-Manufacturing-Company-Ltd-748586188874504 Instagram: instagram.com/tcy_machinery LinkedIn: linkedin.com/company/tcy-machinery-manufacturing-co-ltd Twitter: twitter.com/tien_ltd
