Q-SYS: System Redundancy

For more Q-SYS training curriculum, visit https://training.qsys.com/ Understand the redundancy options available to Q-Sys Systems (including Core, I/O Frame, Network and Amplifier). Core Redundancy allows a second Core to be connected to the network. Should the primary Core go offline for any reason, the secondary Core takes over. Input/Output Redundancy give the designer the option of adding redundant I/O for high priority areas. Network Redundancy may be implemented by simply adding additional network switches an cabling. In the event of a network failure, the Q-SYS components switch over instantly to the backup network. Amplifier Redundancy is made possible with the use of the QSC DAB-801 (DataPort Amplifier Backup panel) which configures five 2-channel QSC DataPort amplifiers so that the fifth amplifier automatically kicks in if a problem is detected with any of the other four (4+1 redundancy). A second DAB-801 may be added for 8 + 1 redundancy.
